Kia EV9 Front Brake Disc – 360mm
These front brake discs are a direct replacement for the Kia EV9. With a large 360 mm diameter, internally vented design and coated surface, they deliver strong braking performance, excellent heat dissipation and good corrosion protection — ideal for the heavy EV9 and UK road conditions.
Key Benefits
- Strong and consistent braking performance
- Internally vented for effective heat dissipation
- Coated surface for corrosion protection
- Direct fit replacement for the Kia EV9
- High-quality aftermarket construction
Specifications
- Outer Diameter: 360 mm
- Brake Disc Thickness: 30 mm
- Minimum Thickness: 28 mm
- Brake Disc Type: Internally vented
- Surface: Oiled and coated
- Centre Diameter: 69 mm
- Height: 48 mm
- No. of Wheel Bolt Holes: 5
Compatibility
Fits Kia EV9 models from 2023 onwards, including:
- EV9 4×4 – 283 kW / 385 hp
- EV9 – 160 kW / 218 hp
- EV9 – 150 kW / 204 hp
Replaces Kia OEM part number: 51712-DO100
Aftermarket Part Numbers
- Blue Print – ADBP430273
- Febi – 1000174
Installation
Professional installation recommended. Always replace brake discs in pairs and bed in new discs correctly for optimal performance and safety.
Pro tip: Replace the front brake pads at the same time as the discs for balanced braking and best long-term results.
Explore More Kia EV9 Parts
| Attributes | |
|---|---|
| Brake Disc Thickness | 30 mm |
| Brake Disc Type | internally vented |
| Centre Diameter | 69 mm |
| Height or Thickness | 48 mm |
| Minimum Thickness of Brake Disc | 28 mm |
| No. of Fixing Holes | 2 |
| No. of Wheel Bolt/Stud Holes | 5 |
| Outer Diameter | 360 mm |
| Pitch Circle Diameter | 114,3 mm |
| Surface | oiled and coated |
| Suitable to replace | Reference(s) |
|---|---|
| KIA | 51712-DO100 |
| Model | Submodel |
|---|---|
| EV9 4×4 2023 – | (E) – 283 kW / 385 hp |
| EV9 2023 – | (E) – 160 kW / 218 hp |
| EV9 2023 – | (E) – 150 kW / 204 hp |
Kia EV9 Front Brake Disc FAQs
Which Kia EV9 variants do these front brake discs fit?
Fits Kia EV9 from 2023 onwards, including 4×4 and standard variants. Please provide your vehicle registration number for exact confirmation.
Is this a single disc or a pair?
This is a single disc. Order two discs to replace both sides of the front axle.
Should I replace the pads at the same time?
Yes – it is highly recommended to replace discs and pads together for balanced braking performance and safety.
Do I need a wheel alignment after fitting?
No – brake disc replacement does not normally require a wheel alignment.
Is this an original Kia part or aftermarket?
This is a high-quality aftermarket brake disc that matches original specifications and performance.
