Renault Zoe Front Wheel Hub
This front wheel hub is for the Renault Zoe 57, 65, 68 and 80 kW and is supplied without the bearing. It has a 4-stud, 100 mm PCD and fits the left or right side.
Replace the hub if the wheel mounting face is damaged or corroded, the studs or threads are damaged, or the hub was damaged when the old bearing was removed.
This is Febi part number 102185, made by the bilstein group.
Febi is a brand of the bilstein group, a German parts maker that supplies replacement parts for cars and vans across the world. Each part is made to match the original in fit and function, so it fits without modification. Getting the right part first time saves time in the workshop, so compare the numbers on your old part with the ones listed here before you order. Keep the old part until the new one is fitted and working, so you can compare them side by side if you need to.
The table below shows the Renault versions listed in the bilstein group parts finder, with each note word for word. Listed in the parts finder for the Renault Zoe 57, 65, 68 and 80 kW. Not listed for the Zoe 100 kW. Compare the Renault part number on your existing part with the numbers on this page before ordering.
Key Benefits
- Front hub, bearing not included
- 4 x 100 mm PCD
- Fits left or right
- For the Zoe 57 to 80 kW
- Febi quality from the bilstein group
Specifications
- Fitting Position: Front axle, left or right
- Contents: Hub without bearing
- Wheel Bolt Holes: 4
- Pitch Circle Diameter: 100 mm
- Outer Diameter: 121.6 mm
- Inner Diameter: 24 mm
- Height: 75 mm
- Part Number: Febi 102185
Replaces Renault part numbers 40 20 220 48R, 82 00 046 549 and 82 00 308 649.
Installation
Professional installation recommended. Press the hub into a new bearing with the correct tools, clean the mounting face and tighten the hub nut to the service figure.
Explore More Parts
| Attribute | Value |
|---|---|
| Fitting Position | Front axle, left or right |
| Contents | Hub without bearing |
| Wheel Bolt Holes | 4 |
| Pitch Circle Diameter | 100 mm |
| Outer Diameter | 121.6 mm |
| Inner Diameter | 24 mm |
| Height | 75 mm |
| Part Number | Febi 102185 |
Fits The Following Renault Models
| Model | Submodel |
|---|---|
| Renault Zoe (2012 –) | (E) – 57 kW / 77 hp |
| Renault Zoe (2012 –) | (E) – 65 kW / 88 hp |
| Renault Zoe (2012 –) | (E) – 68 kW / 92 hp |
| Renault Zoe (2012 –) | (E) – 80 kW / 109 hp |
Renault Zoe Front Wheel Hub FAQs
Which part numbers does it replace?
Replaces Renault part numbers 40 20 220 48R, 82 00 046 549 and 82 00 308 649. The Febi part number is 102185.
Is the bearing included?
No. The hub is supplied without a bearing. We list the front bearing kits separately.
Does it fit the Zoe 100 kW?
No. The parts finder lists it for the Zoe 57, 65, 68 and 80 kW.
Will it fit my Renault Zoe?
Listed in the parts finder for the Renault Zoe 57, 65, 68 and 80 kW. Not listed for the Zoe 100 kW. Check the notes in the fitment table and compare the Renault part number on your existing part.
Is this a genuine Renault part?
No. It is a quality replacement part made by the bilstein group to match the original in fit and function.
